Description

The Symbol/ Motorola DS 6700 series delivers the functionality of both, a 1D and 2D barcode scanner.  The Symbol DS6700 was designed to capture data and images within a single multi-use device.  The DS6700 also enhances employee productivity, superior document clarity, and is all accomplished in a rugged exterior casing

• 6 ft./1.8m drop specification, tempered glass exit window Designed to endure the rigors of everyday use for maximum reliability and uptimes; reduces downtime and TCO
• Multiple on-board interfaces; universal cable compatible Easy to install; futureproof — today’s cradle can connect to tomorrow’s host
• 360° omni-directional scanning; wide working range, laser aiming pattern Easy to use; no need to align item and scanner; virtually no training required
• Optional hands-free Intellistand Enables presentation scanning and automatic switching between hands-free and handheld modes

Physical Characteristics

---



Dimensions:6.55 in. H x 4.72 in. L x 2.82 in. W 16.6 cm H x 11.9 cm L x 7.1 cm W

Weight: 6.4 oz. (182 g)

Voltage and Current: 5 +/-10%VDC @ 350 mA

Color: Cash Register White (shown) or Twilight Black



Performance Characteristics

---



Light Source: Aiming: 650 nm laser diode Illumination: 630 nm LED

Field of View: SR – Standard range: 34° V x 43° H (Vertical x Horizontal) DC – Document capture: 35° V x 44° H

Roll / Pitch / Yaw: SR – Standard range: 360°, ±65°, ±60° DC – Document capture: 360°, ±65°, ±60°

Symbology Decode Capability

---



1-D: UPC/EAN and with supplementals, Code 39, Code 39 Full ASCII, Tri-optic Code 39, RSS variants, UCC/EAN 128, Code 128, Code 128 Full ASCII, Code 93, Codabar (NW1), Interleaved 2 of 5, Discrete 2 of 5, MSI, Codell, IATA, Bookland EAN, Code 32

PDF417 (and Variants): PDF417, microPDF417 and composite codes

Postal: U.S. Postnet and Planet, U.K., Japan, Australian, and Dutch

2-D: MaxiCode, DataMatrix (ECC 200), QR Code and Aztec

Print Contrast: 25% minimum reflectance

Motion Tolerances: Horizontal velocity: 5 in. (12.7 cm) per second

Interfaces Supported: DS6707: RS-232C (Standard, Nixdorf, ICL, and Fujitsu); USB (Standard, IBM SurePOS, Macintosh) DS6708: Includes above plus IBM 468x/469x, keyboard wedge and Synapse connectivity.

---

Note: National Drug Codes (NDC) can be encoded in various symbologies. The DS6708-DL can be programmed to parse these codes using Advanced Data Formatting (ADF) rules

Imaging Characteristics (DS6707 Only)

---



Image (Pixels): 1.3 Megapixel: 1280 pixels H x 1024 pixels V

Graphics Format Support: Images can be exported as Bitmap, Jpeg, and Tiff

Image Transfer Speed: USB 1.1: Up to 12 Megabits/second RS232: Up to 115 kb baud rate

Image Transfer Time: Typical USB application is ~ 0.2 seconds with a compressed Jpeg of 100 kb

Imaging Distance: Minimum Distance (Vertical x Horizontal) Document Sizes: (Approximate) 2 1/8 x 3 3/8 in. (5.4 x 8.6 cm) 2.4 in. (6.1 cm) 4 x 6 in. (10.2 x 15.2 cm) 5.7 in. (14.5 cm) 5 x 7 in. (12.7 x 17.8 cm) 6.9 in. (17.5 cm) 8 x 11 in. (21.6 x 28 cm) 11.9 in. (30.2 cm) Ranges are from the nose of the scanner and are based on DC – Document Capture focus only.

*Note: Imaging characteristics only apply to the DS6707. The DS6708 does notsupport image transfer.

User Environment

---

Sealing: IP41 (Water and Dust Resistant)

Operating Temperature: 32° to 122° F / 0° to 50° C

Storage Temperature: -40° to 158° F / -40° to 70° C

Humidity: 5% to 95%, non-condensing

Drop Specifications: Withstands multiple 6 ft. (1.8m) drops to concrete

Ambient Light Immunity: Immune to normal artificial indoor and natural outdoor (direct sunlight) lighting.

Regulatory

---

Electrical Safety: UL6950-1, CSA C22.2 No. 60950-1, EN60950-1 / IEC60950-1

Laser Safety: EN60825-1:1994 +A1: 2002 +A2 :2001, IEC60825-1, 21CFR1040.10 and 21CFR1040.11, CDRH Class II, IEC Class 2

EMI/RFI: FCC Part 15 Class B, ICES-003 Class B, CISPR 22, CISPR 24; Medical electrical equipment: EN60601-1-2: 2002

Environmental: Compliant with RoHS directive 2002/95/EEC

Mounting Options Intellistand with adjustable height: 5–10 in. (12.7–25.4 cm) (Accessories): and adjustable angle: 0°–90° Desktop and wall-mount holders are also available.

Power Supplies: Power supplies are available for applications that don’t supply power over the host cable.
